Piston Seal - PS024

  • Features :

    Piston seal profile PS024 consists of five piece seal set for sealing pistons with one elastomer sealing component, two antiextrusion support rings and two L-shape guide rings.


  • Composition :
Component
Sealing Ring
Backup rings
L rings
Material
Nitrile Butadiene Rubber
Polyurethane
PA6 + 40% GLASS
Royal Code
NBR78
PUDB65
PG6040

For further compound detail please refer Royal seal materials.

  • Less space required for seal and guide elements.
    Prevents distortion inside the groove.
    Single Piece Piston with one groove.
    No extrusion into the radial sealing gap.
    Suitable for rapid energisation.
    Sealing component protected against twisting.
    Zero leakage.    		 Mobile Hydraulics.
    Injection moulding machines.
    Machine tools.
    Piston Accumulator.
    Agricultural equipment.
    Standard cylinders.
    Properties :
    Application :

General Technical Data:
Working Pressure (max.) 315 Bar
Temperature range -20 to 100°C
Surface Speed (max.) 0.5 m/s.
